Document overview
Workshop Manual for SAME ZF T-7100 from the Tractor components – Transmission – ZF family. Digital PDF in English with 209 pages.
The corresponding English table of contents contains 8 sections and 63 individual topics.
Main sections included
- Technical characteristics
- Method of intervention
Document details
- Brand: SAME
- Family: Tractor components – Transmission – ZF
- Model: ZF T-7100
- Document type: Workshop Manual
- Language: English
- Pages: 209
- File size: 25.07 MiB
- Format: Digital PDF download
Compatibility
Before purchasing, verify that your machine model and reference code match SAME ZF T-7100.
Complete table of contents
Technical characteristics
Transmission
- Transmission
- Transmission detachment points
- Rear PTO
Rear axle
- Rear axle
Hydraulic system
- Gear pump for ZF 7100 gearbox
- Gear pump for transmission ZF 7100
- Pressure test points on the electro-hydraulic shift control module
Method of intervention
D0 – Transmission
- Checking the transmission oil level
- Changing the transmission oil
- Changing the transmission oil filter
- Rear axle-powershift transmission detachment/attachment
- Electro-hydraulic road/field shift control unit
- Joining the POWERSHIFT transmission/clutch housing
- Main clutch
- Clutch housing
- Clutches A – B
- Adjustment of bearing clearance – clutch unit A/B
- Clutches C – D
- Adjustment of bearing clearance – clutch unit D/C
- Removal of the POWERSHIFT assembly
- Output shaft – POWERSHIFT transmission
- Adjustment of bearing clearance – output shaft
- Output shaft
- Torsional spring plate
- Main shaft
- dual gear shaft
- Adjustment of bearing clearance – clutches A/B/C/D and dual gear shaft
- Adjustment of bearing clearance – dual gear shaft
- Selector shaft
- Positioning and adjustment of selector rods and selector forks
- Adjustment of the PTO control
- Bevel pinion assembly
- Creeper
- Creeper unit cover
- Ground speed PTO
- Adjustment of bearing clearance: 0 – 0.15 mm
- Adjustment of end float
- PTO transmission
- Adjustment of the clutch shaft bearing
- Adjustment of flanged shaft bearing
- Four-wheel drive assembly
- Four-wheel drive
- Transmission shaft – 4WD shaft – Version without front axle suspension
- Transmission shaft – 4WD shaft – Version with front axle suspension
- Disassembly of the electro-hydraulic shift control module
- Proportional valve and speed sensor – main clutch
E0 – Rear axle
- Checking the oil level of the rear axle final drives
- Changing the rear axle final drives oil
- Final drive housing
- Adjustment of bearing preload of rear axle shaft support
- Adjustment of planet carrier end float
- Rear brakes
- Adjustment of the rear brake
- Rear differential
- Adjustment of the crown wheel
- Adjustment of the bearing preload
- Adjustment of the braking device
R0 – Rear lift
- Rear lift
- Bush
- Lift control valve
- Draft sensor
- Position sensor
- Checking and calibrating the position sensor
