Document overview
Workshop Manual for SAME ZF ECCOM 1.5 from the Tractor components – Transmission – ZF family. Digital PDF in English with 229 pages.
The corresponding English table of contents contains 6 sections and 81 individual topics.
Main sections included
- Technical characteristics
- Method of intervention
Document details
- Brand: SAME
- Family: Tractor components – Transmission – ZF
- Model: ZF ECCOM 1.5
- Document type: Workshop Manual
- Language: English
- Pages: 229
- File size: 52.84 MiB
- Format: Digital PDF download
Compatibility
Before purchasing, verify that your machine model and reference code match SAME ZF ECCOM 1.5.
Complete table of contents
Technical characteristics
Transmission
- Rear PTO
- Transmission
Rear axle
- Rear axle
Method of intervention
- Index Repair instructions
D0 – Transmission
- Changing the transmission oil
- Removal of transmission
- Disassembly of the clutch control block
- Disassembly of the system control block
- Disassembly of the pump
- Separation of the transmission halves
- Disassembly of the intermediate housing
- Disassembly of the front wheel drive
- Disassembly of clutch KV/KR and double gear
- Disassembly of clutch KV
- Disassembly of clutch KR
- Disassembly of the output gear
- Disassembly of the input shaft (hydrostatic unit)
- Disassembly of the central shaft (clutch KV/KR)
- Disassembly of the intermediate gear
- Disassembly of the multi-disk brake (BG)
- Disassembly of the drum selector gear (planetary transmission)
- Disassembly of the ring gear P4/BG and clutch K3/K4
- Disassembly of planetary drive P4
- Disassembly of the central shaft
- Disassembly of clutch K1/K2
- Disassembly of planetary drive P3
- Disassembly of planetary drive P2
- Disassembly of planetary drive P1
- Disassembly of the hydrostatic unit
- Reassembly of the clutch housing
- Reassembly of the hydrostatic unit
- Reassembly of the drum selector gear (planetary transmission)
- Reassembly of planetary drive P1
- Reassembly of planetary drive P2
- Reassembly of planetary drive P3
- Reassembly of clutch K1/K2
- Reassembly of the central shaft
- Reassembly of planetary drive P4
- Reassembly of clutch K3/K4 and ring gear P4/BG
- Reassembly of the multi disk brake (BG)
- Reassembly of the intermediate housing
- Reassembly of the input shaft (hydrostatic unit)
- Reassembly of the intermediate gear
- Reassembly of the central shaft (clutch KV/KR)
- Reassembly of the output gear
- Reassembly of the pump
- Reassembly of clucth KV/KR
- Reassembly of clutch KV
- Reassembly of clutch KR
- Reassembly of the front wheel drive
- Joining of the preassembled transmission halves
- Setting of the axial play drum selector gear/quill shaft (KV/KR) – Axial play= 0.20 … 0.40 mm
- Setting of the axial play of the KV/KR bearing – Axial play= 0.00 … 0.08 mm
- Setting of the axial play of the double gear bearing – Axial play= 0.00 … 0.08 mm
- Setting of the axial play of the front wheel drive – Axial play= 0.025 … 0.1 mm
- Reassembly of the system control block
- Reassembly of the clutch control block
- Reassembly of the speed and inductive sensor
- Pump Drive flange
- Disassembly of the Pump Drive flange
- Adjusting bevel gear set ( … <- )
- Adjusting bevel gear set ( -> … )
- Removing the rear pinion
- PTO clutch
- Disassembling PTO control clutch
- Rear power take off unit
- Disassembling the rear power take off unit
- Adjustment of selector sleeve position
- Adjusting the handbrake device
E0 – Rear axle
- Bleeding the braking circuit
- RH rear wheel carrier
- LH rear wheel carrier
- Disassembly of LH/RH rear axle
- Adjustment of rear half-shaft bearings
- Disassembly of the planet carrier
- Rear differential
- Disassembly of the rear differential
- Rear axle brake discs and braking assembly
- Renewal of brake seals
- Adjusting the EPB – Bowden assembly
- Rear brakes
