Document overview
Digital Workshop Manual documentation for model DEUTZ FAHR 2040W from the Series 2W family. Language: English; 490 pages.
The corresponding English table of contents contains 32 sections and 132 individual topics.
Main sections included
- Introduction
- Safety
- Technical characteristics
- Method of intervention
- Wiring diagrams
- Service Info
Document details
- Brand: DEUTZ FAHR
- Family: Series 2W
- Model: 2040W
- Document type: Workshop Manual
- Language: English
- Pages: 490
- File size: 261.18 MiB
- Format: Digital PDF download
Compatibility
Before purchasing, verify that your machine model and reference code match DEUTZ FAHR 2040W.
Complete table of contents
Introduction
- Tightening Torques
- Pump tightening torques
- Wheel rim to hub screws and nuts tightening torques
- Tightening torques for nuts and bolts of electrical connections
- Installation of solenoid valves and cartridge valves
- Installation of quick couplers
Safety
Preface
- Important notes concerning safety
Important safety information
- Recognising hazards
- Indications for persons in contact with the tractor
Safety rules
- Risks during tractor preparation
- Risks during maintenance
- Work on machine systems
- Special disassembly/assembly/inspection procedures
Safety pictograms
- Replacing safety pictograms
Environmental risks
- Hazards associated with the operating environment
Technical characteristics
Transmission
- Transmission configuration
Front axle
- Front axle
Hydraulic system
- Auxiliary utilities hydraulic circuit.
- Hydraulic steering circuit
Method of intervention
B0 – Engine
- Complete engine
- Separating engine / transmission
- Engine flywheel
- Alternator drive belt
- Ancillary utility belt
C0 – Engine accessories
- Replacing the coolant
- Engine air fan
- Coolant radiator
- Hydraulic steering fluid reservoir.
- Air filter
- Fuel pre-filter
- Bleeding the fuel circuit
- Fuel tank
- Starter motor
- Exhaust pipe
- Exhaust silencer
D0 – Transmission
- Changing the transmission oil
- Clutch thrust bearing
- Thrust plate and clutch disc
- Separating the gearbox housing from the rear gearbox housing
- Disassembling the centre gearbox casing
- Planetary reduction gearbox
- Disassembly of the planetary reduction gearbox
- 4WD clutch casing
- Disassembling of the 4WD selector casing
- Rear pinion
- Range selector fork
- Gear selector and reverse shuttle rods inside gearbox
- Rear PTO casing
- Disassembling the rear PTO casing
- Power-Take-Off (PTO) control adjustment
E0 – Rear axle
- Right-hand rear axle
- Disassembling rear axle
- Adjustment of wet type brake
- Adjustment of dry type brake
- Adjustment of dry type brake
- Adjustment of hand brake
- RH brake carrier
- LH brake carrier
- Disassembling the brake carrier
- Rear brake discs
- Differential lock selector fork
- Rear differential
- Removing rear differential
F0 – Front axle
- Front 4WD shaft
- Rear 4WD shaft
- Front axle
- Front axle
- Complete front carrier
G0 – Bodywork – Cab – Platform
- Platform
- Seat controls mount
- Engine hood and front hood panels
- Roll bar
- Lower hood guard
- Right hand rear mudguard
- Left hand rear mudguard
- Instrument cluster
- Instrument cluster
- Front turn indicators
- Turn indicator and mirror mount
- External rear-view mirrors
- Seat
- Brake and clutch pedals
- Gear selector and reverse shuttle rod mount
- Steering column
- Steering wheel
H0 – Hydraulic system
- Transmission and ancillaries oil pump
- Power steering pump
- Transmission oil filter
- Hydrostatic steering (orbitrol)
- Ancillary utility distributor
- Disassembling the auxiliary utility distributors and couplers
- Rear lift distributor
L0 – Electrical system
- Battery
- Alternator
- Instrument panel
R0 – Rear lift
- Rear lift
- Disassembling the rear lift
- Controls adjustment for lifter
- 3-point linkage
S0 – Wheels
- Front Wheels
- Rear wheels
V0 – Ballast – towing hitches
- Rear tow hitch
- Rear wheel ballasts
- Front ballast
Wiring diagrams
- Wire colour reference table
- Functional diagram
Service Info
A0 – TRACTOR
- Diagnostics 2026 subscription
- After-sales 2026 subscription
- SERVICE NEWS RESEARCH GUIDE
- Diagnostics 2025 subscription
- After-sales 2025 subscription
- Diagnostics 2023 subscription
- Diagnostics 2024 subscription
- Diagnostics 2022 subscription
- Diagnostics 2021 subscription
- After-sales 2024 subscription
- After-sales 2023 subscription
- After-sales 2022 subscription
- After-sales 2021 subscription
- After-sales 2019 subscription
- Diagnostics – 2020 subscription
- After-sales – 2020 subscription
B0 – ENGINE
- Deutz AG engine oil specifications
C0 – ENGINE ACCESSORIES
- Diagnostic protocol – AdBlue – Float level unit
- Filter and prefilter tool p/n 5.9035.865.0
- SCR AREA DAMAGED SENSORS
F0 – FRONT AXLE
- Bevel gear set loosing screws
- Check the front axle steering knuckles for wear
- Steering behavior check procedure
G0 – BODYWORK – CAB
- Air conditioning system recharging
H0 – HYDRAULIC AND PNEUMATIC SYSTEM|
- Hydraulic CUNA trailer braking kit (ITALY)
- Single connection hydraulic braking kit availability update – only for EUROPEAN market
- L0 – ELECTRIC AL SYSTEM
