Workshop Manual

VIRTUS 140

Serial Number: WSXDB00200TS10001
€110

This document in other languages

SKU: SAME.W.DB0.57054281d2ed.en Category:

Workshop Manual PDF for SAME VIRTUS 140 → WSXDB00200TS10001, VIRTUS (STAGE 4) family. Document language: English; 1,658 pages.

SKU: SAME.W.DB0.57054281d2ed.en
Category:

Document overview

Workshop Manual PDF for SAME VIRTUS 140 → WSXDB00200TS10001, VIRTUS (STAGE 4) family. Document language: English; 1,658 pages.

The corresponding English table of contents contains 51 sections and 530 individual topics.

Main sections included

  • Introduction
  • Safety
  • Technical characteristics
  • Calibrations and electronic diagnosis
  • Method of intervention
  • Wiring diagrams
  • Service Info

Document details

  • Brand: SAME
  • Family: VIRTUS (STAGE 4)
  • Model: VIRTUS 140
  • Starting serial number: WSXDB00200TS10001
  • Document type: Workshop Manual
  • Language: English
  • Pages: 1,658
  • File size: 455.38 MiB
  • Format: Digital PDF download

Compatibility

Before purchasing, verify that your machine model and reference code match SAME VIRTUS 140 → WSXDB00200TS10001.
