SDFManuals

Workshop Manual

CRONO 75

Serial Number: NNZML20200BL00001
€110

This document in other languages

SKU: LAM.W.ML2.8b75386880d3.en Category:

Workshop Manual for LAMBORGHINI CRONO 75 → NNZML20200BL00001 from the CRONO (FARMOTION STAGE 5) family. Digital PDF in English with 543 pages.

SKU: LAM.W.ML2.8b75386880d3.en
Category:

Document overview

Workshop Manual for LAMBORGHINI CRONO 75 → NNZML20200BL00001 from the CRONO (FARMOTION STAGE 5) family. Digital PDF in English with 543 pages.

The corresponding English table of contents contains 37 sections and 243 individual topics.

Main sections included

  • Introduction
  • Safety
  • Technical characteristics
  • Calibrations and electronic diagnosis
  • Method of intervention
  • Wiring diagrams
  • Service Info

Document details

  • Brand: LAMBORGHINI
  • Family: CRONO (FARMOTION STAGE 5)
  • Model: CRONO 75
  • Starting serial number: NNZML20200BL00001
  • Document type: Workshop Manual
  • Language: English
  • Pages: 543
  • File size: 165.00 MiB
  • Format: Digital PDF download

Compatibility

Before purchasing, verify that your machine model and reference code match LAMBORGHINI CRONO 75 → NNZML20200BL00001.

Complete table of contents

  • Introduction
    • Tightening torques
    • Pump tightening torques
    • Wheel nut/screw tightening torques
    • Tightening torques for nuts and bolts of electrical connections
    • Installation of solenoid valves and cartridge valves
    • Installation of quick couplers
    • Units of measurement and conversion factors
  • Safety
    • Preface
      • Important notes concerning safety
    • Important safety information
      • Recognising hazards
      • Indications for persons in contact with the tractor
    • Safety rules
      • Risks during tractor preparation
      • Risks during maintenance
      • Work on machine systems
      • Special disassembly/assembly/inspection procedures
    • Safety pictograms
      • Replacing safety pictograms
    • Environmental risks
      • Hazards associated with the operating environment
  • Technical characteristics
    • Engine
      • Introduction – Engines
      • Cold start system (preheat glow plugs)
      • Engine cooling system
      • Engine intake system
      • Engine injection system – low pressure circuit
      • Exhaust backpressure, engine oil temperature
      • Fuel injection system – Common Rail System
      • Engine air intake system
      • Turbocharging system
      • Exhaust gas recirculation system (EGR)
      • Exhaust aftertreatment system
      • Technical data and exhaust gas after-treatment systems – KF stage 5 engine
      • Technical data, rockers – tappets
      • Technical data and dimensions: valves – valve springs
      • Technical data and dimensions: heads – valve guides – valve seats
      • Technical data: counter-rotating masses
      • Technical data: timing system gears
      • Camshaft technical data
      • Technical data: Connecting rods
      • Technical data: pistons – piston rings
      • Technical data: crankshaft
      • Technical data: cylinder block
    • Transmission
      • Transmission
      • Clutch housing
      • Gearbox and shuttle assembly
      • Range gearbox and parking brake assembly
      • Four-wheel drive engagement assembly
      • Rear PTO
    • Hydraulic system
      • Optional hydraulic circuit 3
      • Base hydraulic circuit
    • Electrical equipment
      • FARMotion engine sensors
      • Sensors and components of the FARMotion engine exhaust system
      • FARMotion engine components
      • Engine wiring loom
      • Electro-injector wiring loom
      • Preheat glow plug wiring loom
  • Calibrations and electronic diagnosis
    • Diagnostic tools
      • ECUs
    • ECU alarms
      • SDF Severity of alarms
      • ECU ALARMS
    • Software management
      • ECUs firmware update
      • On-board instruments (Cluster/Display) flashing
  • Method of intervention
    • B0 – Engine
      • Engine-transmission mating flange
      • Engine
      • Alternator, water pump and A/C compressor belt
      • Engine flywheel
      • Crankshaft pulley
      • Coolant manifold
      • Oil heat exchanger
      • Tightening procedure for engine components
      • Adjusting oil pump gear backlash
      • Aligning water pump and crankshaft pulleys
      • Adjusting PTO gear backlash
      • Test of the thermostat valve
      • Engine block-gearbox connector flange
      • Cooling jets
      • Engine flywheel
      • Belt tensioner mounting plate.
      • Automatic belt tensioner
      • Air compressor belt
      • Ancillary utility belt
      • Crankshaft pulley and tone wheel
      • Crankshaft pulley complete with tone wheel
      • Crankshaft
      • Disassembling pistons and connecting rods
      • Cylinder sleeves
      • Power take off drive
      • Front timing cover
      • Rear flange
      • Cylinder head covers
      • Pushrods
      • Cylinder heads
      • Intermediate gear and timing
      • Disassembling the cylinder heads
      • Engine oil and filter
      • Turbocharger oil pipes
      • Blow-by filter
      • Blow-by oil vapour pipe
      • Oil sump
      • Oil pump
      • Oil vapour pipe
      • Electro-injectors and common rail
      • Thermostat valve
      • Coolant manifold
      • Oil heat exchanger
      • Engine coolant pump
      • EGR exhaust gas recirculation pipe
      • EGR exhaust gas cooling pipe
      • EGR manifold
      • Disassembly of the EGR manifold
      • Exhaust gas pressure line
      • Exhaust manifold
      • Intake manifold
      • Turbocharger
      • Mass air flow sensor
      • EGR valve
      • AdBlue injector
      • NOx sensor
      • DOC outlet side exhaust temperature sensor
      • DOC inlet side exhaust temperature sensor
      • Exhaust gas pressure sensor
      • Throttle valve actuator
      • Alternator
      • Boost pressure sensor and air temperature sensor
      • Mass air flow sensor
      • Crankshaft speed sensor
      • Camshaft timing sensor
      • Engine oil pressure switch
      • Coolant temperature sensor
      • Engine oil temperature sensor
      • Fuel pressure sensor
      • Water in fuel sensor
    • C0 – Engine accessories
      • Engine air intake fan
      • Air filter
      • Electric starter motor
      • Alternator mount
      • Transverse plate
      • Mounting brackets
      • Fuel pump
      • Fuel prefilter
      • Fuel filter
      • Filter mounting plate
      • High pressure fuel pump
      • Glow plug
      • Preheat relay
      • Starter motor
      • Exhaust pipe
      • DOC outlet side exhaust flange
      • DOC inlet side exhaust flange
      • DOC exhaust silencer
      • Air compressor
    • D0 – Transmission
      • Draining and filling the transmission oil
      • Separating front gearbox housing from rear gearbox housing
      • Clutch plate wear check
      • Disassembling the gearbox input shaft
      • Clutch plates
      • Thrust plate assembly
      • Internal PTO drive shaft
      • Disassembly of the main shaft
      • Adjusting endfloat of the secondary shaft gears
      • Disassembling the secondary shaft
      • Complete gearbox assembly
      • Complete gearbox assembly
      • Range selector rod cover
      • Disassembling the gear selector rod
      • Pinion
      • Range reduction gearbox shaft
      • Bevel gear adjustments
      • Assembly of PTO output shaft ring nut
      • Ground speed PTO shaft
      • PTO output shaft
      • PTO input shaft
      • PTO input shaft disassembly
      • Parking brake disc sectors
      • Disassembling the parking brake lever
      • 4WD engagement device
      • 4WD output shaft in transmission.
      • Disassembly of dual traction output shaft
      • Parking brake unit assembly
    • E0 – Rear axle
      • Bleeding air from the hydraulic brake system
      • Left-hand rear axle
      • Disassembling the planetary gear unit
      • Rear brake discs
      • Brake carriers
      • Rear differential lock control fork
      • Rear differential
      • Removing the rear differential
    • F0 – Front axle
      • Front axle
      • Disassembling the front axle differential – Complete assembly
      • Differential locking device adjustment
      • Differential lock
      • Pinion-differential assembly
      • Disassembling the bevel gear set
      • Adjustment of the differential preload
      • Adjusting pinion position
      • Adjusting pinion/crown wheel backlash
      • Adjusting pinion bearing preload
      • Pinion-differential assembly
      • Disassembling the steering cylinder
      • Planetary reduction gearbox
      • Adjusting bearing preload
      • Disassembly of the planetary reduction gearbox
      • Front axle 4WD
      • Complete steering knuckle housing
      • Front brake discs
      • Front axle brake piston
    • H0 – Hydraulic system
      • Ancillary pump
      • Power steering pump
    • L0 – Electrical system
      • Battery
      • Alternator
      • Engine control unit
      • Oil regulator valve block pressure switch
    • R0 – Rear lift
      • Rear lift – Complete assembly
      • Hitch control distributor
      • Disassembling the lift control distributor
    • S0 – Wheels
      • Front Wheels
      • Rear wheels
    • V0 – Ballast – towing hitches
      • Front ballasts and support
      • Rear wheel ballasts
  • Wiring diagrams
    • W-TECH – ELECTRICAL SECTION
    • Wiring looms
  • Service Info
    • A0 – TRACTOR
      • Diagnostics 2026 subscription
      • After-sales 2026 subscription
      • SERVICE NEWS RESEARCH GUIDE
      • Diagnostics 2025 subscription
      • After-sales 2025 subscription
      • Diagnostics 2023 subscription
      • Diagnostics 2024 subscription
      • After-sales 2024 subscription
      • After-sales 2023 subscription
    • B0 – ENGINE
      • Leakage from turbo inlet oil pipe
      • FARMotion seal ring leakage
      • Belt Tensioner FarMotion Engine
    • C0 – ENGINE ACCESSORIES
      • M339 error code on FarMotion Stage 5 models
      • Diagnostic protocol – AdBlue – Float level unit
      • Filter and prefilter tool p/n 5.9035.865.0
      • SCR AREA DAMAGED SENSORS
    • F0 – FRONT AXLE
      • Bevel gear set loosing screws
    • G0 – BODYWORK – CAB
      • SERVICE NEWS – Brake Fluid Reservoir vent missing
      • Oil leakage from easy-lift cylinder 0.036.2115.4
    • H0 – HYDRAULIC AND PNEUMATIC SYSTEM|
      • Hydraulic CUNA trailer braking kit (ITALY)
      • Single connection hydraulic braking kit availability update – only for EUROPEAN market
      • Steering Malfunction below 0°C at first engine start
    • L0 – ELECTRIC AL SYSTEM
      • SERVICE NEWS – M334-M335-M430-M28-M427 New Engine SW release A09 (FarMotion Stage 5)
      • SerDia4.0
      • PTO switch not working
    • V1 – AFTERMARKET KITS
      • Check correct installation of braking KIT
      • Instructions for kit aftersales
